Tool Holder Drive Key Tool Taper Gauges

Share |

Measures the size and radius of HSK tool holder drive keys

Click on image to enlarge

Download PDF: Tool Holder Drive Key Tool Taper Gauges (410.240)

Description

Complete set with case includes measuring ring with dial indicator, measuring gauge for lower deviation, measuring gauge for upper deviation, mean deviation and setting gauge for dial indicator.

Function

The setting gauge is placed into the gauge ring, and the dial indicator is set to zero. The measuring gauge 1 (second gauge pictured) is then used to measure the lower deviation of the drive key, and the measuring gauge 2 (third gauge) for upper deviation.

Parts

Taper								Order Number
HSK-A/C 32								410.240.132.000
HSK-A/C 40								410.240.140.000
HSK-A/C 50								410.240.150.000
HSK-A/C 63								410.240.163.000
HSK-A/C 80								410.240.180.000
HSK-A/C 100								410.240.190.000
HSK-A/C 125								410.240.192.000
HSK-A/C 160								410.240.196.000
