Overview: Morse Taper Gauges

Series 410 Dial Indicator Tool Taper Gauges

Both measuring gauges are set to zero with the calibrated taper plug gauge. When an HSK tool holder is inserted in the ring gauges, deviations in diameters d2 or d3 are shown on the indicator.

Taper Plug Gauges With Flange

Taper gauges can be custom-manufactured to customer specifications. Hard chrome-plate and tungsten carbide gauges also available.

Cases are not included. Contact us for high quality gauge crib and travel case options.

Taper Plug Gauges Without Flange

Machine Tool Service Kits

Machine tool service kits from TAC Rockford include all common preventive gauges for a specific machine tool taper in one convenient kit.

Kits are customized to a specific machine taper and include drawbar pullforce gauges, runout test arbors, tool changer alignment tool, spindle taper gauge¹ and accessories such as a spindle taper wiper. Contact us for gauges included

Already have some of the gauges? We can customize a kit with only the additional items needed.

Looking for a different combination of gauges? We can customize a kit to fit your specific requirements.

¹Taper gauge included with steep taper only, optional for HSK
