Click on image to enlarge
Download PDF: Tool Dynamic Economic Tool Balancing Systems (550.110)
Description
For measuring in two planes (dynamic). Long tools must be balanced in two planes in order to eliminate the couple unbalance. The handling is done by an integrated keyboard and screen, which is clearly designed. Furthermore the Economic Plus has an integrated drawer for accessories.
Works very precisely and with an adapter system which can be used for all kinds of tool holders. Measurement in one plane (static). Particularly very sensible for short tool-holders, because of the couple unbalance being very low. Easy handling with integrated keyboard and screen
Contact Us About This Item
