Machine Tool Gauges > Milling Spindle Gauges > Tool Changer Alignment Gauges

Improper alignment between tool changer pockets, changer arms, and the machine spindle can cause premature wear on tool changer components and the spindle taper. Tool changer alignment tools from TAC Rockford can help with initial set-up of the tool changer, as well as periodic verification of correct alignment as part of a preventive maintenance program.

Steep Taper Tool Changer Alignment Gauge

Available for Steep Taper 30, 40, 50, and 60

440.800

Details PDF

Capto Tool Changer Alignment Gauge

Available for Capto C3, C4, C5, C6, C8, C8X, C10

440.C00

Details PDF

HSK Tool Changer Alignment Gauges

Available for HSK-A 25, 32, 40, 50, 63, 80, 100, 125, and 160

440.100

Details PDF
