Machine Tool Gauges > Milling Spindle Gauges > Steep Taper Dimensional Gauges

Spindle taper gauges are used to check for worn tapers on machine spindles, as well as for verification when regrinding or manufacturing spindle tapers. As with tool holders, a correctly made and non-worn taper is critical for a strong connection between spindle and tool holder. Units are available for CAT/DIN/BT taper in basic contact gauges, dial indicator gauages, as well as air gauges. For HSK, we offer dial indicator, electronic, and air gauges.

Steep Taper Spindle Plug Gauges

Available for Steep Taper 30, 40, 45, 50, 55, 60, 65

430.100

Details PDF

Tool Taper Sleeve Gauges

Available for Steep Taper 30, 40, 45, 50, 55, 60, 65

430.110

Details PDF
