Machine Tool Gauges > Milling Spindle Gauges > HSK Taper Dimensional GaugesSpindle taper gauges are used to check for worn tapers on machine spindles, as well as for verification when regrinding or manufacturing spindle tapers. As with tool holders, a correctly made and non-worn taper is critical for a strong connection between spindle and tool holder. Units are available for CAT/DIN/BT taper in basic contact gauges, dial indicator gauages, as well as air gauges. For HSK, we offer dial indicator, electronic, and air gauges. Dial Indicator Spindle Taper Gauges To ensure sustained accuracy at HSK interfaces, we recommend comparison measuring of the geometry of HSK tool shanks and spindles at regular intervals. These checks should... 410.310Pneumatic Spindle Taper Gauges Non-contact measuring with nozzles results in high accuracy and consistency of measuring results. The measuring range can be increased with the built-in dial indicator. This... 410.320When inserted in the spindle, the "go" gauge should be in contact with the plane face. The "no go" gauge should not contact the face. Two measuring gauges in storage case:... 410.330Pneumatic HSK Spindle Gauge Kits Gauging kit for HSK spindles with pneumatic measuring system. The Multifunctional Measuring and Control Device is designed for high precision and multifunctional capabilities.... 415.210 |
