Machine Tool Gauges

TAC Rockford carries a wide variety of gauges for the machine tool industry for both machine builders and end users using both standard and HSK taper machines: runout arbors, tool taper, spindle taper, drawbar clamping force, and others. Most gauges are available from stock.

Contact us for more information on any of the gauges listed below, or if you do not see what you are looking for.

Milling Spindle Gauges

Drawbar Force Gauges

This critical element–the tool clamping force–is often never measured after a machine is put into service.

Runout Test Arbors

Spindle runout arbors offer a quick and easy way to verify that a machine spindle is running true after a crash, after a machine has been moved, or periodically as a performance check.

HSK Taper Dimensional Spindle Gauges

Units are available for HSK tapers in dial indicator gauges, electronic gauges, and air gauges.

Steep Taper Dimensional Spindle Gauges

Units are available for CAT/DIN/BT tapers in basic contact gauges, dial indicator gauges, as well as air gauges.

Drawbar Stroke Verification

Correct drawbar stroke in the spindle is critical to reliable machine operation.

Tool Holder Gauges

Dial Indicator Tool Taper Gauges (HSK)

Complete set consisting of taper plug gauge, taper calibrating rings with dial indicator, and certificate.

410.210

Details PDF

Electronic Tool Taper Gauges (HSK)

Measuring set with storage case includes taper plug gauge, taper measuring ring with four transducers, and certificate.

410.220

Details PDF

30° Clamping Angle Gauges (HSK)

Measuring gauge with storage case: includes dial indicator holder, dial indicator, centering piece, and calibrated master.

410.230

Details PDF

Tool Holder Drive Key Gauges (HSK)

Complete set includes measuring ring with dial indicator, measuring gauges for lower and upper deviations, mean deviation and setting gauge for dial indicator.
